Features

• High Strength

5083 aluminum provides excellent strength-to-weight performance, suitable for heavy-duty and structural applications.

• Superior Corrosion Resistance

Excellent resistance to seawater, moisture, and harsh environments, making it ideal for marine and outdoor applications.

• Excellent Weldability

Provides outstanding welding performance with stable mechanical properties after fabrication.

• Good Formability

Suitable for stamping, bending, and forming processes, especially for medium-thickness components.

• Excellent Durability

Maintains reliable performance under demanding conditions and long-term service environments.

Specifications

Item	Specification
Alloy	5083 Aluminum
Chemical Composition (%)	Al Balance, Mg 4.0–4.9, Mn 0.40–1.0, Cr 0.05–0.25, Si ≤0.40, Fe ≤0.40, Cu ≤0.10, Zn ≤0.25, Other Elements (Each) ≤0.05, Other Elements (Total) ≤0.15
Temper	O, H32, H34, H116
Thickness	0.5 mm – 10 mm
Diameter	50 mm – 1500 mm (Customized Available)
Surface Finish	Mill Finish / Bright Finish / Anodized Finish
Edge	Mill Edge / Trim Edge / Smooth Punched Edge
Processing Method	Punching / Stamping / Deep Drawing / Spinning
Standard	ASTM B209 / EN AW-5083 / JIS H4000

Typical Mechanical Properties

Property	5083-O
Tensile Strength	270–350 MPa
Yield Strength	≥125 MPa
Elongation	≥20%
Hardness (Approx.)	75–90 HB
Density	2.66 g/cm³
Electrical Conductivity	Approx. 29–35% IACS
Melting Point	Approx. 570–640°C

Applications

• Offshore / Coastal High-Pressure Thread-Sealed Aluminum Covers

Threaded aluminum covers for ship storage tanks, high-pressure chemical reagent dispensing caps, sealed covers for offshore outdoor storage containers, and LNG small container end covers. Featuring high-strength thread rolling technology, they resist thread stripping and maintain long-term leak-proof performance without corrosion in seawater and high-salt storage environments.

• Marine & Offshore Engineering Aluminum Discs

Used for ship equipment end covers, marine lighting reflector bases, seawater desalination equipment liners, and small pressure-bearing discs on decks. Certified by CCS (China Classification Society), these discs offer excellent resistance to marine salt spray corrosion and wave impact.

• LNG Low-Temperature Storage Tanks & Pressure Vessel Heads

Applied in circular heads for liquid nitrogen/liquid oxygen cryogenic tanks, chemical corrosion-resistant storage tanks, and bottom plates for refrigerated transport vehicle tanks. They maintain stable mechanical properties under ultra-low-temperature conditions with excellent weldability and sealing performance.

• Heavy-Duty High-End Pressure Cookware & Kitchen Equipment

Used for commercial large-capacity pressure cookers, industrial cooking pots, and portable pressure-bearing water storage containers for vehicles. The aluminum body provides outstanding rigidity, resists denting and deformation during long-term high-temperature cooking, and delivers durable corrosion resistance in humid kitchen environments.

• Coastal Heavy-Duty Outdoor Traffic Signs & Curtain Walls

Applications include circular reflective signs for docks and offshore ports, decorative aluminum discs for offshore wind power facilities, and curtain walls for coastal industrial buildings. Designed to withstand strong winds, salt spray, and harsh marine environments without deformation or corrosion over many years.
