1100 aluminum wire is the preferred choice for applications requiring high conductivity, excellent corrosion resistance, and easy fabrication at a competitive cost. While it does not offer high mechanical strength, its processing flexibility and reliability make it a classic and economical solution for a wide range of industrial uses.
Description
Features
- High Purity
≥99.0% aluminum, ensuring stable and consistent performance,
- Excellent Corrosion Resistance
Suitable for humid, chemical, and outdoor environments,
- Good Electrical & Thermal Conductivity
Ideal for electrical and heat-transfer applications
- Superior Formability
Easy to draw, bend, twist, and weld,
- Lightweight & Non-Magnetic
Supports lightweight design requirements.
Specifications
| Item | Specification |
|---|---|
| Alloy | AA 1100 |
| Aluminum Content / Chemical Composition | Al ≥ 99.0%, Fe ≤ 0.95%, Si ≤ 0.95%, Cu ≤ 0.05%, Mn ≤ 0.05%, Zn ≤ 0.10%, Ti ≤ 0.03%, Others ≤ 0.05% |
| Temper | O, H12, H14, H16 (customized) |
| Diameter Range | 0.2 – 12.0 mm |
| Form | Coil, spool, cut length |
| Surface Finish | Bright, smooth, oil-free |
| Electrical Conductivity | ≥ 59% IACS |
| Density | 2.71 g/cm³ |
| Tensile Strength | O temper: 70–110 MPa H14 temper: 95–135 MPa |
| Elongation | ≥ 20% (O temper) |
Packaging
| Packaging Type | Weight | Dimensions |
|---|---|---|
| Plastic Reel | 7 kg/reel | Outer Diameter: 270 mmBore Diameter: 52 mmHeight: 105 mm |
| Drum (Small) | 25–100 kg/drum | Outer Diameter: 460 mm Height: 280 mm |
| Drum (Medium) | 25–100 kg/drum | Outer Diameter: 570 mm Height: 380 mm |
| Drum (Large) | 25–100 kg/drum | Outer Diameter: 570 mm Height: 740 mm |
| Bundle | 10–40 kg/bundle | Outer Diameter: 570 mm Inner Diameter: 340 mm Height: 170 mm |
Applications
- Electrical conductors and grounding wires.
- Cable shielding and aluminum braiding.
- Transformer windings and coil wires.
- Chemical equipment and corrosion-resistant components.
- Packaging wires, sealing wires, and general-purpose binding wires.
- Rivets, fasteners, and low-load mechanical parts.
